Konik Disk Yaylar
398 ürün
Milenlerdeki, cıvata başlarının altındaki ve vanaların ucundaki gerilimi korumak ve bileşenleri ayırmak için sunduğumuz en güçlü disk yaylar. Yaylı kilit pullarından farklı olarak, basınçları azaldığında tekrar tekrar orijinal yüksekliklerine dönerler. Belleville disk yayları olarak da bilinir.
| Görsel | Fiyat | ID | Dış Çap | Kalınlık | Malzeme | Çalışma yükü | Yay Tipi | Yükseklik | Düz Yük | Pul Tipi | Disk Yay Tipi | Çalışma Yükünde Sapma | Performans | Çalışma Yükünde Sıkıştırılmış Yükseklik | Parça No |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Konik Disk Yaylar | |||||||||||||||
 | ₺2.899 | 0.093" | 0.187" | 0.007" | 302 Stainless Steel, Stainless Steel | 6 lb. | Disk | 0.013" | 10 lbf | Konik | Konik | 0.003" | Corrosion Resistant, High Load, Stackable | 0.01" | 9713K51 |
 | ₺3.294 | 0.093" | 0.187" | 0.007" | High-Carbon Steel, Steel | 6 lb. | Disk | 0.013" | 10 lbf | Konik | Konik | 0.003" | Yüksek Yük, İstiflenebilir | 0.01" | 9712K51 |
 | ₺2.844 | 0.093" | 0.187" | 0.01" | 302 Stainless Steel, Stainless Steel | 15 lb. | Disk | 0.015" | 28 lbf | Konik | Konik | 0.002" | Corrosion Resistant, High Load, Stackable | 0.013" | 9713K52 |
 | ₺3.294 | 0.093" | 0.187" | 0.01" | High-Carbon Steel, Steel | 15 lb. | Disk | 0.015" | 28 lbf | Konik | Konik | 0.002" | Yüksek Yük, İstiflenebilir | 0.013" | 9712K52 |
 | ₺1.484 | 0.125" | 0.25" | 0.009" | 302 Stainless Steel, Stainless Steel | 11 lb. | Disk | 0.017" | 17 lbf | Konik | Konik | 0.004" | Corrosion Resistant, High Load, Stackable | 0.013" | 9713K53 |
 | ₺1.545 | 0.125" | 0.25" | 0.009" | High-Carbon Steel, Steel | 11 lb. | Disk | 0.017" | 17 lbf | Konik | Konik | 0.004" | Yüksek Yük, İstiflenebilir | 0.013" | 9712K53 |
 | ₺1.400 | 0.125" | 0.25" | 0.013" | 302 Stainless Steel, Stainless Steel | 26 lb. | Disk | 0.02" | 48 lbf | Konik | Konik | 0.003" | Corrosion Resistant, High Load, Stackable | 0.017" | 9713K54 |
 | ₺1.344 | 0.125" | 0.25" | 0.013" | High-Carbon Steel, Steel | 26 lb. | Disk | 0.02" | 48 lbf | Konik | Konik | 0.003" | Yüksek Yük, İstiflenebilir | 0.017" | 9712K54 |
 | ₺3.909 | 0.125" | 0.375" | 0.0185" | 302 Stainless Steel, Stainless Steel | 33 lb. | Disk | 0.028" | 61 lbf | Konik | Konik | 0.005" | Corrosion Resistant, High Load, Stackable | 0.023" | 9713K314 |
 | ₺2.928 | 0.125" | 0.375" | 0.019" | High-Carbon Steel, Steel | 41 lb. | Disk | 0.028" | 73 lbf | Konik | Konik | 0.005" | Yüksek Yük, İstiflenebilir | 0.023" | 9712K16 |
 | ₺3.611 | 0.138" | 0.281" | 0.01" | 302 Stainless Steel, Stainless Steel | 12 lb. | Disk | 0.02" | 23 lbf | Konik | Konik | 0.005" | Corrosion Resistant, High Load, Stackable | 0.015" | 9713K31 |
 | ₺1.650 | 0.138" | 0.281" | 0.01" | High-Carbon Steel, Steel | 15 lb. | Disk | 0.02" | 23 lbf | Konik | Konik | 0.005" | Yüksek Yük, İstiflenebilir | 0.015" | 9712K11 |
 | ₺3.711 | 0.138" | 0.281" | 0.013" | 302 Stainless Steel, Stainless Steel | 20 lb. | Disk | 0.021" | 37 lbf | Konik | Konik | 0.004" | Corrosion Resistant, High Load, Stackable | 0.017" | 9713K311 |
 | ₺1.584 | 0.138" | 0.281" | 0.013" | High-Carbon Steel, Steel | 24 lb. | Disk | 0.021" | 43 lbf | Konik | Konik | 0.004" | Yüksek Yük, İstiflenebilir | 0.017" | 9712K12 |
 | ₺1.523 | 0.138" | 0.281" | 0.015" | 302 Stainless Steel, Stainless Steel | 33 lb. | Disk | 0.023" | 62 lbf | Konik | Konik | 0.004" | Corrosion Resistant, High Load, Stackable | 0.019" | 9713K55 |
 | ₺1.584 | 0.138" | 0.281" | 0.015" | High-Carbon Steel, Steel | 33 lb. | Disk | 0.023" | 62 lbf | Konik | Konik | 0.004" | Yüksek Yük, İstiflenebilir | 0.019" | 9712K55 |
 | ₺270 | 0.142" | 0.281" | 0.021" | 718 Nickel, Nickel | 95 lb. | Disk | 0.033" | 135 lbf | Konik | Konik | 0.004" | Corrosion Resistant, High Load, High Temperature, Highly Corrosion Resistant, Low Temperature, Stackable | 0.03" | 97125K111 |
 | ₺1.843 | 0.142" | 0.344" | 0.025" | 718 Nickel, Nickel | 147 lb. | Disk | 0.038" | 210 lbf | Konik | Konik | 0.005" | Corrosion Resistant, High Load, High Temperature, Highly Corrosion Resistant, Low Temperature, Stackable | 0.033" | 97125K112 |
 | ₺1.634 | 0.156" | 0.312" | 0.011" | 302 Stainless Steel, Stainless Steel | 18 lb. | Disk | 0.022" | 27 lbf | Konik | Konik | 0.006" | Corrosion Resistant, High Load, Stackable | 0.016" | 9713K56 |
 | ₺1.584 | 0.156" | 0.312" | 0.011" | High-Carbon Steel, Steel | 18 lb. | Disk | 0.022" | 27 lbf | Konik | Konik | 0.006" | Yüksek Yük, İstiflenebilir | 0.016" | 9712K56 |
 | ₺1.878 | 0.156" | 0.312" | 0.017" | 302 Stainless Steel, Stainless Steel | 41 lb. | Disk | 0.025" | 75 lbf | Konik | Konik | 0.004" | Corrosion Resistant, High Load, Stackable | 0.021" | 9713K57 |
 | ₺1.967 | 0.156" | 0.312" | 0.017" | High-Carbon Steel, Steel | 41 lb. | Disk | 0.025" | 75 lbf | Konik | Konik | 0.004" | Yüksek Yük, İstiflenebilir | 0.021" | 9712K57 |
 | ₺3.711 | 0.164" | 0.343" | 0.013" | 302 Stainless Steel, Stainless Steel | 21 lb. | Disk | 0.024" | 38 lbf | Konik | Konik | 0.006" | Corrosion Resistant, High Load, Stackable | 0.018" | 9713K312 |
 | ₺2.622 | 0.164" | 0.343" | 0.013" | High-Carbon Steel, Steel | 25 lb. | Disk | 0.024" | 38 lbf | Konik | Konik | 0.006" | Yüksek Yük, İstiflenebilir | 0.018" | 9712K13 |
 | ₺672 | 0.164" | 0.343" | 0.016" | 302 Stainless Steel, Stainless Steel | 36 lb. | Disk | 0.026" | 65 lbf | Konik | Konik | 0.005" | Corrosion Resistant, High Load, Stackable | 0.021" | 9713K11 |
 | ₺705 | 0.164" | 0.343" | 0.016" | High-Carbon Steel, Steel | 36 lb. | Disk | 0.026" | 65 lbf | Konik | Konik | 0.005" | Yüksek Yük, İstiflenebilir | 0.021" | 9712K111 |
 | ₺1.605 | 0.164" | 0.343" | 0.019" | 302 Stainless Steel, Stainless Steel | 55 lb. | Disk | 0.028" | 93 lbf | Konik | Konik | 0.005" | Corrosion Resistant, High Load, Stackable | 0.023" | 9713K14 |
 | ₺1.862 | 0.164" | 0.343" | 0.019" | High-Carbon Steel, Steel | 55 lb. | Disk | 0.028" | 93 lbf | Konik | Konik | 0.005" | Yüksek Yük, İstiflenebilir | 0.023" | 9712K14 |
 | ₺750 | 0.168" | 0.344" | 0.025" | 718 Nickel, Nickel | 144 lb. | Disk | 0.045" | 205 lbf | Konik | Konik | 0.005" | Corrosion Resistant, High Load, High Temperature, Highly Corrosion Resistant, Low Temperature, Stackable | 0.04" | 97125K113 |
 | ₺429 | 0.168" | 0.406" | 0.03" | 718 Nickel, Nickel | 203 lb. | Disk | 0.045" | 290 lbf | Konik | Konik | 0.006" | Corrosion Resistant, High Load, High Temperature, Highly Corrosion Resistant, Low Temperature, Stackable | 0.039" | 97125K114 |
 | ₺1.328 | 0.19" | 0.375" | 0.015" | 302 Stainless Steel, Stainless Steel | 34 lb. | Disk | 0.027" | 55 lbf | Konik | Konik | 0.006" | Corrosion Resistant, High Load, Stackable | 0.021" | 9713K58 |
 | ₺1.379 | 0.19" | 0.375" | 0.015" | High-Carbon Steel, Steel | 34 lb. | Disk | 0.027" | 55 lbf | Konik | Konik | 0.006" | Yüksek Yük, İstiflenebilir | 0.021" | 9712K58 |
 | ₺3.611 | 0.19" | 0.375" | 0.0175" | 302 Stainless Steel, Stainless Steel | 36 lb. | Disk | 0.028" | 68 lbf | Konik | Konik | 0.005" | Corrosion Resistant, High Load, Stackable | 0.023" | 9713K313 |
 | ₺1.829 | 0.19" | 0.375" | 0.018" | High-Carbon Steel, Steel | 46 lb. | Disk | 0.028" | 81 lbf | Konik | Konik | 0.005" | Yüksek Yük, İstiflenebilir | 0.023" | 9712K15 |
 | ₺1.067 | 0.19" | 0.375" | 0.02" | 302 Stainless Steel, Stainless Steel | 60 lb. | Disk | 0.03" | 110 lbf | Konik | Konik | 0.005" | Corrosion Resistant, High Load, Stackable | 0.025" | 9713K59 |
 | ₺1.112 | 0.19" | 0.375" | 0.02" | High-Carbon Steel, Steel | 60 lb. | Disk | 0.03" | 110 lbf | Konik | Konik | 0.005" | Yüksek Yük, İstiflenebilir | 0.025" | 9712K59 |
 | ₺2.012 | 0.19" | 0.375" | 0.03" | 302 Stainless Steel, Stainless Steel | 125 lb. | Disk | 0.036" | 233 lbf | Konik | Konik | 0.003" | Corrosion Resistant, High Load, Stackable | 0.033" | 9713K12 |
 | ₺1.128 | 0.19" | 0.375" | 0.03" | High-Carbon Steel, Steel | 125 lb. | Disk | 0.036" | 233 lbf | Konik | Konik | 0.003" | Yüksek Yük, İstiflenebilir | 0.033" | 9712K112 |
 | ₺2.433 | 0.19" | 0.562" | 0.019" | 302 Stainless Steel, Stainless Steel | 45 lb. | Disk | 0.037" | 67 lbf | Konik | Konik | 0.009" | Corrosion Resistant, High Load, Stackable | 0.028" | 9713K315 |
 | ₺1.656 | 0.19" | 0.562" | 0.019" | High-Carbon Steel, Steel | 45 lb. | Disk | 0.037" | 67 lbf | Konik | Konik | 0.009" | Yüksek Yük, İstiflenebilir | 0.028" | 9712K18 |
 | ₺2.483 | 0.19" | 0.562" | 0.028" | 302 Stainless Steel, Stainless Steel | 87 lb. | Disk | 0.042" | 163 lbf | Konik | Konik | 0.007" | Corrosion Resistant, High Load, Stackable | 0.035" | 9713K316 |
 | ₺1.817 | 0.19" | 0.562" | 0.028" | High-Carbon Steel, Steel | 87 lb. | Disk | 0.042" | 163 lbf | Konik | Konik | 0.007" | Yüksek Yük, İstiflenebilir | 0.035" | 9712K19 |
 | ₺450 | 0.196" | 0.406" | 0.03" | 718 Nickel, Nickel | 200 lb. | Disk | 0.046" | 285 lbf | Konik | Konik | 0.006" | Corrosion Resistant, High Load, High Temperature, Highly Corrosion Resistant, Low Temperature, Stackable | 0.04" | 97125K116 |
 | ₺1.555 | 0.196" | 0.469" | 0.04" | 718 Nickel, Nickel | 403 lb. | Disk | 0.056" | 575 lbf | Konik | Konik | 0.006" | Corrosion Resistant, High Load, High Temperature, Highly Corrosion Resistant, Low Temperature, Stackable | 0.05" | 97125K117 |
 | ₺2.628 | 0.22" | 0.437" | 0.016" | 302 Stainless Steel, Stainless Steel | 40 lb. | Disk | 0.031" | 60 lbf | Konik | Konik | 0.008" | Corrosion Resistant, High Load, Stackable | 0.023" | 9713K17 |
 | ₺2.756 | 0.22" | 0.437" | 0.016" | High-Carbon Steel, Steel | 40 lb. | Disk | 0.031" | 60 lbf | Konik | Konik | 0.008" | Yüksek Yük, İstiflenebilir | 0.023" | 9712K17 |
 | ₺2.261 | 0.22" | 0.437" | 0.02" | 302 Stainless Steel, Stainless Steel | 57 lb. | Disk | 0.032" | 98 lbf | Konik | Konik | 0.006" | Corrosion Resistant, High Load, Stackable | 0.026" | 9713K13 |
 | ₺1.041 | 0.22" | 0.437" | 0.02" | High-Carbon Steel, Steel | 57 lb. | Disk | 0.032" | 98 lbf | Konik | Konik | 0.006" | Yüksek Yük, İstiflenebilir | 0.026" | 9712K113 |
 | ₺2.228 | 0.22" | 0.437" | 0.023" | 302 Stainless Steel, Stainless Steel | 76 lb. | Disk | 0.034" | 139 lbf | Konik | Konik | 0.005" | Corrosion Resistant, High Load, Stackable | 0.029" | 9713K15 |
 | ₺1.002 | 0.22" | 0.437" | 0.023" | High-Carbon Steel, Steel | 76 lb. | Disk | 0.034" | 139 lbf | Konik | Konik | 0.005" | Yüksek Yük, İstiflenebilir | 0.029" | 9712K114 |
 | ₺1.405 | 0.22" | 0.687" | 0.034" | 302 Paslanmaz Çelik | 125 lb. | Disk | 0.05" | 229 lbf | — | Konik | 0.008" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.042" | 9713K16 |
 | ₺933 | 0.22" | 0.687" | 0.034" | Yüksek Karbonlu Çelik | 125 lb. | Disk | 0.05" | 229 lbf | — | Konik | 0.008" | Yüksek Yük, İstiflenebilir | 0.042" | 9712K115 |
 | ₺1.184 | 0.255" | 0.5" | 0.018" | 302 Paslanmaz Çelik | 45 lb. | Disk | 0.034" | 70 lbf | — | Konik | 0.008" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.026" | 9713K61 |
 | ₺1.112 | 0.255" | 0.5" | 0.018" | Yüksek Karbonlu Çelik | 45 lb. | Disk | 0.034" | 70 lbf | — | Konik | 0.008" | Yüksek Yük, İstiflenebilir | 0.026" | 9712K61 |
 | ₺1.705 | 0.255" | 0.5" | 0.022" | 302 Paslanmaz Çelik | 65 lb. | Disk | 0.036" | 115 lbf | — | Konik | 0.007" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.029" | 9713K62 |
 | ₺1.116 | 0.255" | 0.5" | 0.022" | Yüksek Karbonlu Çelik | 65 lb. | Disk | 0.036" | 115 lbf | — | Konik | 0.007" | Yüksek Yük, İstiflenebilir | 0.029" | 9712K62 |
 | ₺1.262 | 0.255" | 0.5" | 0.025" | 302 Paslanmaz Çelik | 95 lb. | Disk | 0.038" | 160 lbf | — | Konik | 0.007" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.031" | 9713K63 |
 | ₺1.112 | 0.255" | 0.5" | 0.025" | Yüksek Karbonlu Çelik | 95 lb. | Disk | 0.038" | 160 lbf | — | Konik | 0.007" | Yüksek Yük, İstiflenebilir | 0.031" | 9712K63 |
 | ₺1.467 | 0.255" | 0.5" | 0.038" | 302 Paslanmaz Çelik | 190 lb. | Disk | 0.047" | 400 lbf | — | Konik | 0.004" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.043" | 9713K64 |
 | ₺1.695 | 0.255" | 0.5" | 0.038" | Yüksek Karbonlu Çelik | 190 lb. | Disk | 0.047" | 400 lbf | — | Konik | 0.004" | Yüksek Yük, İstiflenebilir | 0.043" | 9712K64 |
 | ₺458 | 0.255" | 0.5" | 0.04" | 718 Nikel | 382 lb. | Disk | 0.049" | 545 lbf | — | Konik | 0.006" | Yüksek Yük, Yüksek Korozyon Direnci, Yüksek Sıcaklık, Düşük Sıcaklık, İstiflenebilir | 0.043" | 97125K118 |
 | ₺2.552 | 0.255" | 0.637" | 0.032" | 302 Paslanmaz Çelik | 96 lb. | Disk | 0.048" | 180 lbf | — | Konik | 0.008" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.04" | 9713K317 |
 | ₺2.139 | 0.255" | 0.637" | 0.032" | Yüksek Karbonlu Çelik | 118 lb. | Disk | 0.048" | 222 lbf | — | Konik | 0.008" | Yüksek Yük, İstiflenebilir | 0.04" | 9712K21 |
 | ₺467 | 0.255" | 0.75" | 0.025" | 302 Paslanmaz Çelik | 77 lb. | Disk | 0.049" | 114 lbf | — | Konik | 0.012" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.037" | 9713K18 |
 | ₺422 | 0.255" | 0.75" | 0.025" | Yüksek Karbonlu Çelik | 77 lb. | Disk | 0.049" | 114 lbf | — | Konik | 0.012" | Yüksek Yük, İstiflenebilir | 0.037" | 9712K116 |
 | ₺467 | 0.255" | 0.75" | 0.036" | 302 Paslanmaz Çelik | 147 lb. | Disk | 0.054" | 261 lbf | — | Konik | 0.009" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.045" | 9713K19 |
 | ₺440 | 0.255" | 0.75" | 0.036" | Yüksek Karbonlu Çelik | 147 lb. | Disk | 0.054" | 261 lbf | — | Konik | 0.009" | Yüksek Yük, İstiflenebilir | 0.045" | 9712K117 |
 | ₺1.320 | 0.255" | 0.75" | 0.041" | 718 Nikel | 343 lb. | Disk | 0.062" | 490 lbf | — | Konik | 0.015" | Yüksek Yük, Yüksek Korozyon Direnci, Yüksek Sıcaklık, Düşük Sıcaklık, İstiflenebilir | 0.047" | 97125K119 |
 | ₺1.352 | 0.258" | 0.688" | 0.05" | 718 Nikel | 592 lb. | Disk | 0.091" | 845 lbf | — | Konik | 0.011" | Yüksek Yük, Yüksek Korozyon Direnci, Yüksek Sıcaklık, Düşük Sıcaklık, İstiflenebilir | 0.08" | 97125K121 |
 | ₺2.967 | 0.265" | 0.562" | 0.042" | 302 Paslanmaz Çelik | 400 lb. | Disk | 0.055" | 567 lbf | — | Konik | 0.01" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.045" | 9713K411 |
 | ₺1.928 | 0.265" | 0.562" | 0.042" | Yüksek Karbonlu Çelik | 400 lb. | Disk | 0.055" | 567 lbf | — | Konik | 0.01" | Yüksek Yük, İstiflenebilir | 0.045" | 9712K411 |
 | ₺4.673 | 0.265" | 0.687" | 0.052" | 302 Paslanmaz Çelik | 620 lb. | Disk | 0.069" | 884 lbf | — | Konik | 0.014" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.055" | 9713K412 |
 | ₺2.678 | 0.265" | 0.687" | 0.052" | Yüksek Karbonlu Çelik | 620 lb. | Disk | 0.069" | 884 lbf | — | Konik | 0.014" | Yüksek Yük, İstiflenebilir | 0.055" | 9712K412 |
 | ₺2.694 | 0.265" | 0.812" | 0.061" | 302 Paslanmaz Çelik | 950 lb. | Disk | 0.084" | 1,350 lbf | — | Konik | 0.018" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.066" | 9713K413 |
 | ₺1.755 | 0.265" | 0.812" | 0.061" | Yüksek Karbonlu Çelik | 950 lb. | Disk | 0.084" | 1,350 lbf | — | Konik | 0.018" | Yüksek Yük, İstiflenebilir | 0.066" | 9712K413 |
 | ₺3.489 | 0.281" | 0.875" | 0.05" | 302 Paslanmaz Çelik | 310 lb. | Disk | 0.066" | 445 lbf | — | Konik | 0.013" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.053" | 9713K414 |
 | ₺1.989 | 0.281" | 0.875" | 0.05" | Yüksek Karbonlu Çelik | 310 lb. | Disk | 0.066" | 445 lbf | — | Konik | 0.013" | Yüksek Yük, İstiflenebilir | 0.053" | 9712K414 |
 | ₺3.216 | 0.281" | 0.875" | 0.075" | 17-7 PH Paslanmaz Çelik | 720 lb. | Disk | 0.086" | 1,032 lbf | — | Konik | 0.009" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.077" | 9713K415 |
 | ₺1.950 | 0.281" | 0.875" | 0.075" | Yüksek Karbonlu Çelik | 720 lb. | Disk | 0.086" | 1,032 lbf | — | Konik | 0.009" | Yüksek Yük, İstiflenebilir | 0.077" | 9712K415 |
 | ₺1.584 | 0.317" | 0.625" | 0.022" | 302 Paslanmaz Çelik | 70 lb. | Disk | 0.042" | 105 lbf | — | Konik | 0.01" | Yüksek Yük, Korozyona Dayanıklı, İstiflenebilir | 0.032" | 9713K65 |
