Düz Dişli Bağlantılar için Ultra Kimyasal Dirençli Sert PTFE O-Ringler
20 ürün
Boss O-ringler olarak da bilinen bu O-ringler, düz dişli bağlantılı boru bağlantı parçalarında kullanılır. PTFE'den üretilen bu O-ringler, aşırı sıcaklıklara ve florlu çözücüler, etanol ve aseton gibi agresif kimyasallara dayanıklıdır. Ayrıca sert yapıları nedeniyle esnek O-ringlere göre montajı daha zordur. Bu O-ringler, gıda ile doğrudan temasa uygun FDA sertifikasına sahiptir. Bunları pompa şaftlarında, karıştırma tanklarında ve kimyasalları veya ilaçları işleyen diğer ekipmanlarda bulabilirsiniz. Bunları erkek bağlantı parçasının dişlerinin arkasına takın. Dişi bağlantı parçasına doğru sıkarken, O-ring sıkışarak sıkı bir sızdırmazlık sağlar. Hepsinin torbasında kürlenme tarihi ve izlenebilir parti numarası bulunur.
| Görsel | Fiyat | Dış Çap | Malzeme | ID | Genişlik | Boru Dış Çapı | Kesit Şekli | Birlikte Kullanım | Dash Numarası | Maksimum Sıcaklık | Minimum Sıcaklık | Renk | Fractional ID | Kesirli Genişlik | Çevre | Sertlik Derecesi | Fractional OD | Sertlik | Gıda Endüstrisi Standardı | Karşılanan Teknik Özellikler | Parça No |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Düz Dişli Bağlantılar için Ultra Kimyasal Dirençli Sert PTFE O-Ringler | |||||||||||||||||||||
 | ₺2.103 | 332", 0.297" | Plastic, PTFE | 0.185" | 0.056" | 332" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 901 | 500° F | -300° F | Beyaz | 316 | 116 | Yiyecek ve İçecek | Sert | 516 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N11 |
 | ₺2.111 | 18", 0.367" | Plastic, PTFE | 0.239" | 0.064" | 18" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 902 | 500° F | -300° F | Beyaz | 14 | 564 | Yiyecek ve İçecek | Sert | 38 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N12 |
 | ₺2.192 | 316", 0.429" | Plastic, PTFE | 0.301" | 0.064" | 316" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 903 | 500° F | -300° F | Beyaz | 516 | 564 | Yiyecek ve İçecek | Sert | 716 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N13 |
 | ₺1.685 | 14", 0.495" | Plastic, PTFE | 0.351" | 0.072" | 14" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 904 | 500° F | -300° F | Beyaz | 2364 | 564 | Yiyecek ve İçecek | Sert | 12 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N14 |
 | ₺1.739 | 516", 0.558" | Plastic, PTFE | 0.414" | 0.072" | 516" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 905 | 500° F | -300° F | Beyaz | 2764 | 564 | Yiyecek ve İçecek | Sert | 916 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N15 |
 | ₺2.375 | 38", 0.624" | Plastic, PTFE | 0.468" | 0.078" | 38" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 906 | 500° F | -300° F | Beyaz | 1532 | 564 | Yiyecek ve İçecek | Sert | 58 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N16 |
 | ₺2.486 | 716", 0.694" | Plastic, PTFE | 0.53" | 0.082" | 716" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 907 | 500° F | -300° F | Beyaz | 1732 | 332 | Yiyecek ve İçecek | Sert | 4564 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N17 |
 | ₺2.546 | 12", 0.818" | Plastic, PTFE | 0.644" | 0.087" | 12" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 908 | 500° F | -300° F | Beyaz | 2132 | 332 | Yiyecek ve İçecek | Sert | 5364 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N18 |
 | ₺2.495 | 916", 0.9" | Plastic, PTFE | 0.706" | 0.097" | 916" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 909 | 500° F | -300° F | Beyaz | 2332 | 332 | Yiyecek ve İçecek | Sert | 2932 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N19 |
 | ₺2.645 | 58", 0.949" | Plastic, PTFE | 0.755" | 0.097" | 58" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 910 | 500° F | -300° F | Beyaz | 4964 | 764 | Yiyecek ve İçecek | Sert | 6164 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N2 |
 | ₺1.478 | 1116", 1.095" | Plastic, PTFE | 0.863" | 0.116" | 1116" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 911 | 500° F | -300° F | Beyaz | 78 | 18 | Yiyecek ve İçecek | Sert | 1 764 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N21 |
 | ₺2.486 | 34", 1.156" | Plastic, PTFE | 0.924" | 0.116" | 34" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 912 | 500° F | -300° F | Beyaz | 1516 | 18 | Yiyecek ve İçecek | Sert | 1 532 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N22 |
 | ₺1.542 | 1316", 1.218" | Plastic, PTFE | 0.986" | 0.116" | 1316" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 913 | 500° F | -300° F | Beyaz | 1 | 18 | Yiyecek ve İçecek | Sert | 1 732 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N23 |
 | ₺3.146 | 78", 1.279" | Plastic, PTFE | 1.047" | 0.116" | 78" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 914 | 500° F | -300° F | Beyaz | 1 116 | 18 | Yiyecek ve İçecek | Sert | 1 932 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N24 |
 | ₺1.646 | 1", 1.403" | Plastic, PTFE | 1.171" | 0.116" | 1" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 916 | 500° F | -300° F | Beyaz | 1 1164 | 18 | Yiyecek ve İçecek | Sert | 1 1332 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N25 |
 | ₺1.685 | 1 18", 1.587" | Plastic, PTFE | 1.355" | 0.116" | 1 18" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 918 | 500° F | -300° F | Beyaz | 1 2364 | 18 | Yiyecek ve İçecek | Sert | 1 1932 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N26 |
 | ₺2.390 | 1 14", 1.711" | Plastic, PTFE | 1.475" | 0.118" | 1 14" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 920 | 500° F | -300° F | Beyaz | 1 3164 | 18 | Yiyecek ve İçecek | Sert | 1 2332 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N27 |
 | ₺2.973 | 1 12", 1.956" | Plastic, PTFE | 1.72" | 0.118" | 1 12" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 924 | 500° F | -300° F | Beyaz | 1 4764 | 18 | Yiyecek ve İçecek | Sert | 1 3132 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N28 |
 | ₺3.032 | 1 34", 2.326" | Plastic, PTFE | 2.09" | 0.118" | 1 34" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 928 | 500° F | -300° F | Beyaz | 2 332 | 18 | Yiyecek ve İçecek | Sert | 2 2164 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N29 |
 | ₺3.206 | 2", 2.573" | Plastic, PTFE | 2.337" | 0.118" | 2" | Yuvarlak | Bases, Beverage, Brake Fluid, Diluted Salt Solutions, Fluorinated Solvents, Food, Solvents, Acetone, Acid, Alcohol, Animal Oil, Benzene, Boric Acid, Butyl Alcohol, Calcium Hydroxide, Citric Acid, Ethanol, Ethylene Glycol, Glycerin, Grease, Hydraulic Oil, Isopropyl Alcohol, Methanol (Methyl Alcohol), Methyl Ethyl Ketone (MEK), Mineral Oil, Motor Oil, Nitric Acid, Petroleum, Sodium Bicarbonate (Baking Soda), Steam, Sulfonic Acid, Vegetable Oil, Water | 932 | 500° F | -300° F | Beyaz | 2 1132 | 18 | Yiyecek ve İçecek | Sert | 2 3764 | Durometre 55D | FDA Standard, FDA Compliant 21 CFR 177.1550 | SAE AS568, SAE Standard | 6613N3 |
